HR MAX™ 110° Heavy Duty Full Overlay Cam Adjustable Self-close Hinge with Lever-Top Dowels

HR MAX™ 110° Heavy Duty Full Overlay Cam Adjustable Self-close Hinge with Lever-Top Dowels

$3.70
$0.00 USD
Sale Sold out
  • HR Max = Quality backed by Lifetime warranty
  • Lever-top provides toolless installation and removal
  • Heavy duty spring and patented linkage system
  • All metal concealed damper provides a life time of worry-free use
  • 2-stop action
  • Hinge and plate provide 6-way adjustability
  • Cold rolled steel with nickel plating
  • Compatible with 600 series mounting plates
  • 0 mm Crank

Details

Item Number 725.L110.00
Closing Self-close
Cycles 100,000+
Hinge Cup Bore Depth 11.2 mm
Arm Type Straight Arm
Hinge Type European
Mount Centers 45 mm
Cabinet Type Faceframe or Frameless
Pivot Type Dual
ADA Friendly No
Length 118 mm
Packaging Type Small Package
Degree of Opening 110°
Overlay Full
Hinge Crank Amount 0mm
Overlay Adjustment +2 mm, -2 mm
Depth Adjustment +3 mm, -2 mm
Adjustment Type Cam
Sold By Each
Brand HR Max
Series 725 Series
Finish Nickel
Mount Type Lever-Top Dowels
Height 16.5 mm
Width 59 mm
Hinge Cup Diameter 35 mm
Hinge Dowels Lever-Top
Material Steel
Patent US Patent Pending
Certification Grade 2 ANSI/BHMA Certified to ANSI 100,000 Cycles
Warranty Period Limited Lifetime
UPC Code 840002535311


More Information

FEATURES
Heavy duty: ideal for larger doors, heavy usage, as well as standard residential applications
Hinge and plate provide 6-way adjustability
Cold rolled steel with nickel plating
Compatible with 600 Series Plates
NOTES
Full Carton Count 200
Inner Carton Count 200

Resources

Installation Instructions
Certifications
Warranty


SPECIFICATIONS:
